🔧 Ranger - Front Windshield Wiper Blade Replacement

Replacing both front wiper blades restores clear visibility and helps prevent windshield scratches. Your Ranger uses a 26-inch driver-side blade and a 16-inch passenger-side blade with push-button connectors.

Difficulty Level: Beginner | Estimated Time: 10-15 minutes

---

⚠️ Safety & Precautions

• ⚠️ Replace one blade at a time so the sizes are not mixed up.
• 🛡️ Do not let a raised metal wiper arm snap against the windshield.
• 🔋 Battery disconnection is not required.
• 🌧️ Do not operate the wipers until both new blades are securely installed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Mechanic’s gloves (cut-resistant)
• Safety glasses (ANSI Z87.1 rated)
• Microfiber towel (16-inch minimum)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blade set - Driver: 26", Passenger: 16" - Qty: 2

Replace both front blades together for even wiping performance.

---

📋 Before You Begin

• 🅿️ Park your Ranger on level ground, switch off the ignition, and engage the parking brake.
• 🧼 Clean loose dirt from the windshield before installing the blades.
• 📏 Match each new blade to the corresponding old blade before removal.
• 🔒 No infotainment setting, service mode, scan tool, or battery disconnect is needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Protect the windshield

• Wear the ANSI Z87.1 safety glasses and cut-resistant mechanic’s gloves.
• Place the 16-inch microfiber towel on the windshield beneath the driver-side blade.
• The towel cushions the glass if the spring-loaded arm slips.

Step 2: Raise the driver-side wiper arm

• Using your gloved hand, lift the driver-side arm away from the windshield until it remains raised.
• Hold the arm securely while handling the blade.
• Never release an arm without a blade attached.

Step 3: Remove the driver-side blade

• Rotate the blade slightly so you can reach the connector where the blade meets the arm.
• Using your gloved thumb, press the connector’s release button.
• While holding the button, slide the blade straight out of the end of the arm.
• Carefully rest the bare arm on the 16-inch microfiber towel.

Step 4: Install the 26-inch driver-side blade

• Use your gloved hands to align the new 26-inch driver-side blade with the end of the arm.
• Slide the connector into the arm until it clicks into place.
• Pull gently on the blade with your gloved hand to confirm the connector is locked.
• Lower the arm gently onto the windshield.

Step 5: Replace the passenger-side blade

• Move the 16-inch microfiber towel beneath the passenger-side blade.
• Using your gloved hand, lift the passenger-side arm away from the glass.
• Press the connector release button with your gloved thumb and slide the old blade out.
• Slide the new 16-inch passenger-side blade into the arm until it clicks.
• Pull gently to verify it is locked, then lower the arm carefully.

Step 6: Inspect both installations

• Use your gloved hands to confirm both blades sit flat against the windshield.
• Verify the 26-inch blade is on the driver side and the 16-inch blade is on the passenger side.
• Remove the 16-inch microfiber towel from the windshield.
• No fasteners are removed, so there are no torque specifications for this repair.

---

✅ After Repair

• 💧 Start your Ranger and spray windshield-washer fluid onto the glass.
• 👀 Operate the wipers at low speed and confirm both blades move smoothly without striking each other or the windshield trim.
• ✨ Check for streaking, skipping, chatter, or unwiped areas.
• 🛑 Stop the wipers immediately if a blade loosens, then switch off the ignition and reinstall it until the connector clicks.

---

💰 DIY vs Shop Cost

Shop Cost: $45-$90 (parts + labor)

DIY Cost: $25-$55 (parts only)

You Save: $20-$35 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.1-0.2 hours.

---
