🔧 Prius - Front Windshield Wiper Blade Replacement

Replacing the two front wiper blades restores clear, streak-free wiping and helps prevent windshield scratches. Your Prius uses different blade lengths on the driver and passenger sides, so install each blade in the correct position.

Difficulty Level: Beginner | Estimated Time: 10-15 minutes

---

⚠️ Safety & Precautions

• ⚠️ Do not lift the wiper arms until they are placed in the maintenance position.
• ⚠️ Never allow a bare metal wiper arm to snap against the windshield; it can crack the glass.
• ⚠️ Keep the Prius powered off while handling the wiper arms.
• ⚠️ Battery disconnection is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Windshield protection towel
• Nitrile work gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blades - Driver: 28", Passenger: 16" - Qty: 2

Choose direct-fit blades with the correct Toyota push-button/top-lock adapters. Replace both front blades together for even wiping performance.

---

📋 Before You Begin

• 🚗 Park your Prius on level ground and engage the parking brake.
• 📏 Compare the new blades with the old ones before removing anything. The 28-inch blade belongs on the driver side.
• 🧼 Clean loose dirt from the windshield so it cannot scratch the glass.
• 🔌 Leave the wiper arms folded down until maintenance mode is activated.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Place the Wipers in Maintenance Position

• Turn the Prius on, and then turn it completely off with the POWER button.
• Within approximately 45 seconds, move the wiper control stalk upward to the MIST position and hold it for at least two seconds.
• Release the stalk when both wipers move upward and stop near the center of the windshield.
• If they do not move, power the Prius on and off and repeat the sequence.

Step 2: Protect the Windshield

• Put on the nitrile work gloves and safety glasses.
• Place the windshield protection towel under the driver-side blade.
• Carefully lift the driver-side wiper arm away from the glass. Lift only as far as needed.
• Replace one blade at a time.

Step 3: Remove the Driver-Side Blade

• Rotate the old blade slightly so you can see its center adapter.
• Use your fingers to press the adapter’s release button or open its small locking cover, depending on the direct-fit blade installed.
• While holding the release, slide the blade toward the open end of the wiper arm until it disengages.
• Slowly lower the bare arm onto the windshield protection towel. Do not leave it standing unattended.

Step 4: Install the 28-Inch Driver-Side Blade

• Remove the protective packaging from the 28-inch driver-side wiper blade by hand.
• Align the blade adapter with the end of the driver-side arm.
• Slide the blade into the arm until the locking button clicks or the locking cover closes fully.
• Gently pull on the blade to confirm it is locked.
• Lower the wiper arm carefully onto the windshield.

Step 5: Replace the Passenger-Side Blade

• Move the windshield protection towel beneath the passenger-side blade.
• Lift the passenger-side arm and use your fingers to press the adapter release or open its locking cover.
• Slide the old blade out of the arm, then lower the bare arm onto the towel.
• Install the 16-inch passenger-side wiper blade and slide it into place until it clicks or locks securely.
• Gently pull on the blade to verify the connection, then carefully lower the arm.

Step 6: Return the Wipers to Their Parked Position

• Remove the windshield protection towel and confirm both arms are resting against the glass.
• Turn the Prius on and briefly operate the wiper control stalk using the MIST position.
• The wipers should sweep once and return to their normal parked position below the hood edge.

---

✅ After Repair

• 💧 Spray windshield-washer fluid and operate the wipers through several cycles.
• 👀 Confirm both blades move smoothly without streaking, chattering, striking each other, or contacting the windshield trim.
• 🔒 Stop immediately if a blade slips or looks loose, then switch the Prius off and reseat its adapter.
• 🗑️ Remove any plastic blade protectors before operating the wipers.

---

💰 DIY vs Shop Cost

Shop Cost: ₹2,000-₹4,500 (parts + labor)

DIY Cost: ₹1,200-₹3,000 (parts only)

You Save: ₹800-₹1,500 by doing it yourself!

Local labor and blade prices in Sonīpat vary by brand. This repair takes a shop approximately 0.2-0.3 hours.

---
