🔧 F-150 - Front Brake Pad and Rotor Replacement

This repair replaces both front brake rotors and the complete front pad set. Work on one side at a time so the assembled side remains available as a reference.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Support your F-150 with correctly rated jack stands. Never work under a vehicle supported only by a jack.
• ⚠️ Replace front pads and rotors on both sides to maintain even braking.
• ⚠️ Brake dust may be harmful. Do not use compressed air to clean brake components.
• ⚠️ Do not allow the caliper to hang from its rubber brake hose.
• ⚠️ Brake fluid damages paint. Wipe spills immediately and rinse with water.
• ⚠️ Do not press the brake pedal while either caliper is removed.
• ⚠️ Battery disconnection is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3-ton floor jack
• 3-ton jack stands
• Wheel chocks
• 21mm deep socket
• 13mm socket
• 18mm socket
• 21mm socket
• 1/2-inch breaker bar
• 3/8-inch ratchet
• 1/2-inch ratchet
• 10-80 Nm torque wrench
• 50-250 Nm torque wrench
• Disc brake piston compressor (specialty)
• Flat-blade screwdriver
• Dead-blow hammer
• Brake caliper hanger (specialty)
• Stiff nylon cleaning brush
• Wire hub-cleaning brush
• Plastic drain pan
• Brake-fluid syringe
• 150mm metric ruler
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set with installation hardware - Qty: 1
• Front brake rotors - Qty: 2, replace in pairs
• High-temperature silicone brake lubricant - Qty: 1
• Non-chlorinated brake cleaner - Qty: 2 cans
• DOT 3 brake fluid - Qty: 1 small sealed container

---

📋 Before You Begin

• 📋 Park your F-150 on firm, level ground. Shift into Park, apply the parking brake, switch off the engine, and place wheel chocks behind both rear tires.
• 📋 Verify that the replacement rotors match the original rotor diameter and hub opening before dismantling both sides.
• 📋 Open the hood and inspect the brake-fluid reservoir. If it is near MAX, remove a small amount before compressing the caliper pistons.
• 📋 No infotainment service mode, scan-tool command, electronic parking-brake retraction, or battery disconnection is required.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the front wheel nuts

• Use a 21mm deep socket and 1/2-inch breaker bar to loosen each front lug nut about one-half turn while the tires remain on the ground.
• Do not remove the lug nuts yet.

Step 2: Raise and support the truck

• Position the 3-ton floor jack beneath the front crossmember and raise your F-150.
• Place the 3-ton jack stands beneath the reinforced front frame rails, then lower the vehicle onto them.
• Gently push the body to confirm that it is stable before removing either wheel.

Step 3: Remove the front wheels

• Use the 21mm deep socket and 1/2-inch ratchet to remove the lug nuts.
• Remove both front wheels and slide one wheel beneath the frame as an additional safety measure.

Step 4: Check the brake-fluid level

• Use the 150mm metric ruler to note the reservoir level.
• If the fluid is at MAX, use a brake-fluid syringe to remove enough fluid to prevent overflow. Place extracted fluid in the plastic drain pan; never reuse it.

Step 5: Remove the first caliper

• Turn the steering wheel to improve access to the caliper bolts.
• Use a 13mm socket and 3/8-inch ratchet to remove the upper and lower caliper guide-pin bolts.
• If the guide pin turns with the bolt, hold the pin's flats with the appropriately fitting wrench supplied in your tool set while loosening the bolt.
• Lift the caliper from the bracket. Use a flat-blade screwdriver only for gentle assistance if it is tight.
• Support the caliper with a brake caliper hanger. A caliper hanger is a hook that supports the caliper without stressing its hose.

Step 6: Remove the old pads and hardware

• Use a flat-blade screwdriver to remove the inner and outer pads from the bracket.
• Remove the stainless pad-support clips with the flat-blade screwdriver.
• Note the orientation of the inner and outer pads before disposal.

Step 7: Compress the caliper pistons

• Place an old brake pad across both pistons, then use the disc brake piston compressor to press both pistons inward slowly and evenly.
• Watch the brake-fluid reservoir while compressing the pistons. Remove excess fluid with the brake-fluid syringe if it approaches MAX.
• Stop if either piston binds, tilts, or leaks. A sticking or leaking caliper must be repaired before continuing.

Step 8: Remove the caliper bracket

• Use an 18mm or 21mm socket, whichever fits the factory bolt head fully, with the 1/2-inch breaker bar to remove the two caliper-bracket bolts.
• Remove the bracket and keep its bolts clean.
• Photograph hardware positions before cleaning.

Step 9: Remove the old rotor

• Pull off and discard any thin factory assembly clips installed over the wheel studs, using the flat-blade screwdriver.
• Pull the rotor straight from the hub.
• If rust holds it in place, strike only the rotor hat between the wheel studs with the dead-blow hammer. Do not strike the studs or hub.

Step 10: Clean the hub and new rotor

• Use the wire hub-cleaning brush to remove rust from the hub face and center pilot. The rotor must sit completely flat.
• Spray both friction surfaces of the new rotor with non-chlorinated brake cleaner, then wipe them clean with a lint-free shop towel.
• Install the rotor over the wheel studs. Temporarily hold it flat with one lug nut installed by hand.

Step 11: Service the caliper bracket

• Use the stiff nylon cleaning brush and brake cleaner to clean the bracket where the stainless clips sit.
• Install the new pad-support clips by hand in the same positions as the originals.
• Remove each guide pin by hand, wipe it clean, and inspect its rubber boot for tears.
• Apply a thin coating of high-temperature silicone brake lubricant to each smooth guide pin, then reinstall it. Do not use petroleum grease because it can damage the rubber boots.
• Apply only a very thin film of lubricant beneath the stainless clips where they touch the bracket. Keep all lubricant away from rotor and pad friction surfaces.

Step 12: Reinstall the caliper bracket

• Position the bracket over the rotor and start both bolts by hand.
• Use the 50-250 Nm torque wrench and the correctly fitting 18mm or 21mm socket to tighten both bracket bolts to 250 Nm (184 ft-lbs).

Step 13: Install the new pads

• Slide the new inner and outer pads into the support clips by hand.
• Confirm that both pads move smoothly in the bracket without binding.
• Do not touch the pad friction material with greasy gloves.

Step 14: Reinstall the caliper

• Remove the brake caliper hanger and lower the caliper over the new pads. Make sure the hose is not twisted.
• Start both guide-pin bolts by hand to avoid cross-threading.
• Use the 10-80 Nm torque wrench and 13mm socket to tighten the guide-pin bolts to 37 Nm (27 ft-lbs).

Step 15: Repeat on the opposite side

• Use the same listed tools and repeat Steps 5 through 14 on the other front brake assembly.
• Compare both completed sides and confirm that every clip, pad, boot, and hose is correctly positioned.

Step 16: Reinstall the wheels

• Remove the temporary lug nut holding each rotor with the 21mm deep socket.
• Install each wheel and start all lug nuts by hand.
• Use the 21mm deep socket and 1/2-inch ratchet to snug the nuts in a star pattern.
• Raise your F-150 slightly with the 3-ton floor jack, remove the 3-ton jack stands, and lower the tires to the ground.
• Use the 50-250 Nm torque wrench and 21mm deep socket to tighten the lug nuts in a star pattern to 203 Nm (150 ft-lbs).

Step 17: Restore brake pressure

• With the engine off, press and release the brake pedal slowly several times until it becomes firm.
• Do not move your F-150 until the pedal is firm and remains above the floor.
• Inspect the reservoir and add fresh DOT 3 brake fluid only if needed. Keep the level between MIN and MAX.

---

✅ After Repair

• ✅ Check both calipers, hoses, and bleeder screws for brake-fluid leaks.
• ✅ Start the engine and press the brake pedal. It may drop slightly with power assist, but it must remain firm.
• ✅ Test the brakes at walking speed in a clear, level area before entering traffic.
• ✅ Bed in the pads with 8-10 moderate stops from approximately 50 km/h to 10 km/h. Do not stop completely between applications.
• ✅ Drive for 5-10 minutes afterward without heavy braking to cool the brakes. Avoid hard braking for the first 300 km when safely possible.
• ✅ Recheck the brake-fluid level and inspect for leaks after the road test.
• ✅ Recheck wheel-lug torque to 203 Nm (150 ft-lbs) after approximately 80-160 km.

---

💰 DIY vs Shop Cost

Shop Cost: ₹28,000-₹55,000 (parts + labor)

DIY Cost: ₹14,000-₹30,000 (parts only)

You Save: ₹14,000-₹25,000 by doing it yourself!

Sonīpat labor and imported-part prices vary. This repair typically takes a shop approximately 2-3 hours.

---
